VT604G Switched gigabit PDU

€479.70 Tax included

Description

Use cases

Specifications

Extensions

Features

Description

VT604G/ Switched PDU with 4 Outlets with Gigabit Ethernet can be used for manage up to four individual outlets, including:

PDU switch: 4 outlets with 10A, 230V bistable relays.
I/O Controller: analog sensors inputs, CAN, dry contacts, 4 relays, SD, USB, alarm relays, 4G.
Built-in Web Interface: 10/100/1000 Mbit/s, IPv4; IPv6 by demand.
Extensions: 4G modem, Built-In UPS.
Notifications: Telegram, mail; VPN, SMS and voice call in case of LTE modem built-IN.
Processor: 720Mhz dual-core Cortex-A7.

Specification

Device type:

PDU

Switchable outputs:

4 bistable relays 10A 230V

Network Interface:

1000 Mbit/s

Analog ports:

2

CAN:

1

Relays with output 12V:

2

Dry contacts IN:

2

Mounting:

19"

Extensions:

SD, USB-C

Expansions:

4G, RS485, built-In UPS

Status Indicators:

Red (Error), Green Led, Yellow, Orange (Relais)

Processor:

ual core ARM, 720 Mhz, 128 MB

Power inputs:

10A, 230VDC

Operating temperature:

-10° C to +80° C

Origin of goods:

Made in EU

HS Code:

8537 10 910

Use cases

Advanced technology

From sensing to connecting, from data to the power that transforms the world, what we do matters.

Switched Power Outlets

x4 C13 outlets 110-240V AC, 50/60 Hz

Can be manually controlled or automatically using logic schemes.

Redundant Ethernet

Network reservation using LTE 4G modem & LAN port

Rechargeable backup

In case of voltage drop, a monitoring system may work from a battery module.

Complete Control

Monitor devices, transform sensor data into actionable insights, and configure integrations — all within an intuitive web-based interface.

- Monitor real-time data from all connected sensors & devices
- Create automated actions based on defined conditions
- Send Email, Telegram, HTTP request, SNMP or other notifications
- Visualize trends and logs for better decision-making
- Manage users, permissions, and access securely
