K10A AC Current transducer

€88.50 Tax included

Description
Downloads
Use cases
Specifications
Features
Used with

Description

The K10A AC is a simple open-loop AC ammeter capable of measuring currents in the range of 200A-2000A. It connects to the monitoring system via the VT405 transceiver.

This plug-and-play transceiver easily connects to any analog port of Vutlan monitoring devices.

Downloads

How to connect analog sensors
How to configure analog sensors
API: analog sensors

Use cases

VT500 helps maintain environmental conditions for equipment and inventory across various industries.

  • Telecom & Data Centers: Monitoring AC/DC current in rectifier racks, battery banks, and DC distribution lines. Detecting overloads or faults in backup power systems.
  • Industrial Automation: Measuring DC current in PLCs, motors, and production lines. Tracking energy consumption of DC-powered machinery.

Specifications

Type of sensor:
AC Ammeter, Analog sensor
Measured range:
200-2000A
Accuracy:
1%
Operating temperature:
Min. -10° C - Max.80° C
Operating humidity:
Min. 5% - Max. 95% (Non-Condensing)
Power Consumption:
100 mW
Maximum distance:
50-meter cable
Isolation:
2,5 kV
Weight:
300 g
Dimensions:
Size 102 × 100 x 26 mm, hole 40 mm
Power terminals:
4Pin Power terminals 2.54mm, 12V, Ground, Metered
Power supply:
12V DC (supplied from Analog port using RJ9 cable)
Mounting:
Desktop, Wall mount
Manufactured in:
China
HS Code:
9030 33 100
HS Code:
9030 33 100
EAN code:
8588009886730

Sensor features

Vutlan sensors are designed to deliver reliable, real-time environmental monitoring with flexible configuration and clear data visualization. Each sensor integrates seamlessly into your system, providing precise measurements and actionable insights.

- Logic schemes
- Create automated actions based on defined conditions
- Dashboard overview
- Thresholds
- Graphs and Logging

Web UI customizable dashboard
Sensor data logging
High temperature notification alarm
Sensor graph

Monitoring units with analog ports

The following Vutlan monitoring units can have analog pots for analog sensors.
