K6A AC Current transducer

€59 Tax included

Description

The K6A AC is a simple open-loop AC ammeter capable of measuring currents from 0A to 100A. It connects to the monitoring system via the VT405 Current converter. This plug-and-play transceiver easily connects to any analog port of Vutlan monitoring devices. 1

Use cases

  • Electrical Panel Current Monitoring: Measures load current from Hall effect transducers installed on feeders and circuits, enabling remote supervision of power consumption and overload detection
  • Industrial Equipment Monitoring: Supervises motors, pumps, compressors, and production machinery to detect operational changes and unexpected load variations.
  • Overload Detection: Generates alarms when current exceeds predefined thresholds, helping prevent equipment damage and power interruptions.

Order Options / Models

K6A AC 50:
Rated input: 50A
Measured range: 0-50 Aac
K6A AC 100:
Rated input: 100A
Measured range: 0-100 Aac
K6A AC 200:
Rated input: 200A
Measured range: 0-200 Aac
K6A AC 300:
Rated input: 300A
Measured range: 0-300 Aac
K6A AC 400:
Rated input: 400A
Measured range: 0-400 Aac
K6A AC 500:
Rated input: 500A
Measured range: 0-500 Aac

Required Components

VT405 Current Tranceiver

The VT405 current transceiver bridges the measured data from the k6A AC transducer to the Vutlan monitoring system.

VT405 Product page

Technical Specifications


Used for:
Measure Alternating Current
Rated input (Aac):
50A, 100A, 200A, 300A, 400A, 500A
(see order options)
Measured range:
0-50, 0-100, 0-200, 0-300, 0-400, 0-500 Aac
(see order options)
Rated output:
0-5Vdc
Load resistance:
≤250 Ω (for measured range 0-50, 0-100, 0-200 Aac)
≥10 KΩ (for measured range 0-300, 0-400, 0-50 Aac)
Offset current:
≤±0.1 mA (for measured range 0-50, 0-100, 0-200 Aac)
≥15 mV (for measured range 0-300, 0-400, 0-50 Aac)
Supply Voltage:
+12 Vdc
Accuracy:
≤±1.0 %
Linearity error:
≤±1.0 %
Response time:
≤ 350 mS
Power consumption:
≤ 50 mA

Bandwidth:
50/60 Hz
Insulation voltage:
AC 2.5KV 50Hz 1min
Operating temperature:
-10~ +70°C
Storage temperature:
-25~ +85°C
Through hole:
21 mm
Phase:
Single
Coil Structure:
Toroidal
Coil Number:
Auto-transformer
Net Weight:
67g
Outputs:
4 pin terminal, pitch 3.81mm,
G: ground
M: 0-5V
G: Ground
+: +12V DC
HS Code:
9030 33 100

Downloads

K6A AC Flyer
VT405 & K6A AC Current Online User Guide
K6A AC Package Content
